LH-LF130 DC toy motor

SPEED：10300

CURRENT：0.580

TORQU：9.0

OUTPUT：0.96

Consultation

Product Details

型號 MODEL	電壓 VOLTAGE		無負荷 NOLOAD		最大效率點 AT MAXIMUM EFFICIENCY					扭力STALL
	使用范圍 OPERATING RANGE	額定值NOMINAL	轉(zhuǎn)速SPEED	電流 CURRENT	轉(zhuǎn)速SPEED	電流CURRENT	轉(zhuǎn)矩TORQUE	功率OUTPUT	效率 EFF	扭力STALL
	使用范圍 OPERATING RANGE	額定值NOMINAL	rpm	A	rpm	A	g.cm	W	%	g.cm
LFF130A-18100-38V	1.5-6.0V	3VCONSTANT	13500	0.200	10300	0.580	9.0	0.96	56.1	36.0
LFF130SA-2286-38V	1.5-6.0V	3VCONSTANT	11000	0.160	8938	0.690	15.0	1.38	59.2	80.0
LFC130SA-07760-32V	6.0-14.0V	12VCONSTANT	4100	0.018	3129	0.050	9.0	0.29	49.6	38.0
